dry type transformer

Application

dry-type distribution transformer is with features of low loss, compact and light weight, low noise level,clamp-proof,anti-fouling,high mechanical strength, flame resisting, strong overload ability and low partial discharge quality,they are application to power transmission and distribution system,hotel,restaurant,commercial building,stadiums,chemical plants,stations,aiports,offshore drilling platforms,especially to heavy load centers and places with special fire protection requirements

Changan electric could supply a complete range of three phase distribution transformers, including oil-immersed type & cast resin dry-type transformer, designed with increased margins of safety and reliablity,and meet the IEC60076, IEEE Std

Service Condition

Service Condition
a) Suitable for indoor or outdoor application

b)Air temperature: Maximum temperature: +40℃; Minimum temperature:-30℃

c) Humidity: Monthly average humidity 95%; Daily average humidity 90% .

d) Altitude above sea level: Maximum installation altitude: 2000m.

e)Max wind speed:35M/s

f) Ambient air not apparently polluted by corrosive and flammable gas, vapor etc.

g) No frequent violent shake

technical parameter

Type	Dimension of body mm								Install size mm			Weight
	L	W	H	W1	W2	W3	H1	H2	m	n	Dia of foot	kg
SC(B)11-30/10	645	460	660	305	/	145	505	720	400	400	4-Φ19	265
SC(B)11-50/10	690	460	710	305	/	205	780	875	400	400	4-Φ19	300
SC(B)11-80/10	830	460	880	320	300	215	675	765	500	400	4-Φ19	485
SC(B)11-100/10	910	800	955	320	320	225	800	900	550	740	4-18*26	575
SC(B)11-125/10	910	800	925	340	325	240	850	940	550	740	4-18*26	620
SC(B)11-160/10	910	800	1000	335	325	240	780	875	550	740	4-18*26	650
SC(B)11-200/10	940	900	1090	375	325	255	940	1015	550	820	4-18*26	900
SC(B)11-250/10	980	900	1160	365	350	260	1015	1080	550	820	4-18*26	1020
SC(B)11-315/10	1020	900	1235	360	335	260	1080	1210	550	820	4-18*26	1280
SC(B)11-400/10	1110	870	1040	450	350	300	920	950	660	820	4-18*26	1450
SC(B)11-500/10	1110	890	1180	410	355	275	1175	1345	660	820	4-18*26	1560
SC(B)11-630/10	1200	890	1200	405	355	285	1090	1175	660	820	4-18*26	1650
SC(B)11-800/10	1350	890	1250	480	375	345	1100	1185	820	820	4-18*26	1970
SC(B)11-1000/10	1350	890	1420	440	360	370	1205	1345	820	820	4-18*26	2170
SC(B)11-1250/10	1470	890	1380	480	390	370	1245	1375	820	820	4-18*26	3200
SC(B)11-1600/10	1510	900	1500	490	360	370	1490	1290	820	820	4-18*26	3200
SC(B)11-2000/10	1620	1120	1690	490	365	365	1560	1650	1070	1120	4-18*26	3710
SC(B)11-2500/10	1620	1120	1590	500	380	410	1360	1530	1070	1070	4-18*26	4460
