| Nominal diameter of strand inch(mm) | No. of Strands | Strands wire OD | Approx. Weight of strand | Strength Guy wire | |||||||
| utilities Grade | Common Grade | Siemens Martin grade | High-strength | Extra High- | |||||||
| 1/8 | (3.18) | 7 | 0.041 (1.04) | 32 | (48) | 540 (2.402) | 910(4.048) | 1330(5.916) | 1830(8.140) | ||
| 6/32 | (3.97) | 7 | 0.052(1.32) | 51 | (76) | 870(3.870) | 1470(6.539) | 2140(9.519) | 2940 (13.078) | ||
| 3/16 | (4.76) | ? | 0.062 (1.57) | 73 | (109) | 1150(5.115) | 1900(8.452) | 2850(12.677) | 3990 (17.748) | ||
| 7/32 | (5.56) | 3 | 0.104 (2.64) | 88 | (131) | 1400(6.228) | 2340(10.409) | 3500(15.569) | 4900 (21.796) | ||
| 1/4 | 5.56 | 7 | 0.072(1.83) | 98 | (146) | 1540(6.850) | 2560(11.387) | 3850(17.126) | 5400 (24.020) | ||
| 1/4 | (6.35) | 3 | 0.120(3.05) | 117 | (174) | 3150(14.012)(2) | 1860(8.274) | 3040(13.523) | 4730(21.040) | 6740 (29.981) | |
| 1/4 | (6.35) | 3 | 0.120(3.05) | 117 | (174) | 4500 (20.017)(3) | |||||
| 9/32 | (7.14) | 3 | 0.130 (3.30) | 137 | 204) | 2080(9.252) | 3380(15.035) | 5260(23.398) | 7500(33.362) | ||
| 9/32 | (7.14) | 7 | 0.093 (2.36) | 164 | (244) | 4600 (20.462)(1) | 2570(11.432) | 4250(18.905) | 6400(28.469) | 8950 (39.812) | |
| 5/16 | (7.94) | 3 | 0.145 (3.68) | 171 | (255 | 6500 (28.913)(3) | 2490(11.076 | 4090(18.193) | 6350(28.246) | 9100(40.479) | |
| 5/16 | (7.94) | 0.104 (2.64) | 205 | (305) | 3200(14.234) | 5350(23.798) | 8000(35.586) | 11200(49.820) | |||
| 5/16 | (7.94) | 0.109 (2.77) | 225 | (335 | 5000(26.689)(1) | ||||||
| 3/8 | (9.52) | 0.165 (4.19) | 220 | (328) | 8500 (37.810)(3) | 3330(14.813) | 5560(24.732) | 8360(37.187) | 11800(52.489) | ||
| 3/8 | (9.52) | 0.120(3.05) | 273 (407) | 11500(51.155)(4) | 4250(18.905) | 6950(30.915) | 10800(48.040) | 15400(68.503) | |||
| 7/16 | (11.11) | 7 | 0.145 (3.68) | 399 | (595) | 18000(80.068)(4) | 5700(25.355) | 9350(41.591) | 14500(64.499) | 20800(92.523) | |
| 1/2 | (12.70 | 7 | 0.165 (4.19) | 517 | (770) | 25000 (111.206)(4) | 7400 (32.917) | 12100 (53.823 | 18800(83.627) | 26900(119.657) | |
| 1/2 | (12.70) | 19 | 0.100 (2.54) | 504 | (751) | 7620(33.895) | 12700(56.492) | 19100(84.961) | 26700(118.768) | ||
| 9/16 | (14.29) | 7 | 0.188(4.78) | 671 | (1000) | 9600 (42.703) | 15700(69.837) | 24500(108.981) | 35000(155.688) | ||
| 9/16 | (14.29) | 19 | 0.113 (2.87) | 637 | (949) | 9640 (42.881) | 16100(71.616) | 24100(107.202) | 33700(149.906) | ||
| 5/8 | (15.88 | 7 | 0.207(5.26) | 813 | (1211) | 11600(51.599 | 19100(84.961) | 29600(131.667 | 42400(188.605 | ||
| 5/8 | (15.88) | 19 | 0.125 (3.18) | 796 | (1186 | 11000(48.930) | 18100(80.513) | 28100(124.995 | 40200(178.819) | ||
| 3/4 | (19.05) | 19 | 0.150(3.81) | 1155 | (1721) | 16000 (71.172) | 26200(116.543) | 40800(181.487) | 58300 (259.331 | ||
| 7/8 | (22.22) | 19 | 0.177 (4.50) | 1581 | (2356 | 21900197.416 | 35900(159.691) | 55800 (248.211) | 79700(354.523) | ||
| 1 | (25.40) | 19 | 0.20015.08 | 2073 | (3089) | 28700(127.664 | 47000 (209.066 | 73200 (325.610 | 104500(464.839 | ||
| 1 | 25.40) | 37 | 0.143(3.63 | 2057 | (3065) | 28300(125.885 | 462001205.508 | 71900 (319.827 | 02700(456.832) | ||
| 1-1/8 | 28.58) | 的 | 0.161 (4.09) | 2691 | (4010 | 36000(160.136) | 58900 (262.000) | 91600 (407.457) | 130800(581.827) | ||
| 1-1/4 | (31.75) | 的 | 0.179(4.55) | 3248 | (4840) | 44600(198.391) | 73000 (324.720) | 113600(505.318) | 162200(721.502) | ||
