Internal wiring or electronic equipments, widly used in Air conditioners, microwave ovens, electronic sterilizers, electric rice burgers, electronic hot water bottles, electric.
Marking: E529032 9M AWM 21016 24AWG 125 300V XLPE wire FT2
standard: UL 758
Conductor: tinned copper wire
insulation:XLPE
Conductor type:7 strands wire, 11 strands wire
| AWG | Conductor OD | Insulation thickness | wire O.D. | cores # | wires pitch | Conductor resistance |
| mm | mm | mm | # | mm | ohm/KM | |
| 24 | 0.61 | 0.23 | 1.5*3.0 | 2 | 1.5 | 85.9 |
| 24 | 0.61 | 0.23 | 1.5*4.5 | 3 | 1.5 | 85.0 |
| 24 | 0.61 | 0.23 | 0.90 | 4 | 1.5 | 85.9 |
| 24 | 0.61 | 0.23 | 1.00 | 5 | 1.5 | 85.9 |
| 24 | 0.61 | 0.23 | 1.12 | 6 | 1.5 | 85.9 |
color: red black yellow green
packing: 610 m/2000 ft a roll
