High temperature resistance, low temperature reisistance, anti-acid and alkali, fire and aging resistance, inoxid-izability, super flexible.
UL Wire No.： UL3122 UL 3132 UL3135 UL 3512 UL 3530 UL 3239
Type of silicone wire in production: UL3066 UL3069 UL3071 UL 3074 UL3075 UL 3122 UL3123 UL3133 UL3134 UL3135 UL3136 UL3138 UL 3140 UL 3142 UL 3172 UL 3212 UL3213 UL3219 UL 3222 UL3223 UL3239 UL 3240 UL 3241 UL 3251 UL 3252 UL 3253 UL 3254 UL 3256 UL 3304 UL 3350 UL3367 UL 3512 UL 3529 UL 3530 UL 3550 UL3634 UL 4271 UL 4291 UL 4297 UL 4330
Internal wiring or electronic equipmentswidly used in Air conditioners, microwave ovens, electronic sterilizers, electric rice burgers, electronic hot water bottles, electric.
| Conductor | Insulation | 20℃ Maximum Resistanceat(Ω/km) | |||
| AWG | No./mm | Diamater(mm) | Thicknes(mm) | Diamater(mm) | |
| 30 | 7/0.10 | 0.30 | 0.76 | 1.85 | 381 |
| 28 | 7/0.127 | 0.38 | 0.76 | 1.90 | 239 |
| 26 | 7/0.16 | 0.48 | 0.76 | 2.10 | 150 |
| 24 | 11/0.16 | 0.61 | 0.76 | 2.20 | 94.2 |
| 22 | 17/0.16 | 0.76 | 0.76 | 2.30 | 59.4 |
| 20 | 20/0.18 | 0.94 | 0.76 | 2.50 | 36.7 |
| 18 | 32/0.18 | 1.18 | 0.76 | 2.80 | 23.2 |
| 16 | 52/0.18 | 1.49 | 0.76 | 3.10 | 14.6 |
| 14 | 41/0.254 | 1.87 | 0.76 | 3.40 | 8.96 |
| 12 | 65/0.254 | 2.36 | 0.76 | 3.90 | 5.64 |
| 10 | 105/0.254 | 3.00 | 0.76 | 4.60 | 3.546 |
| 8 | 169/0.254 | 4.20 | 1.14 | 6.50 | 2.230 |
| 7 | 7/29/0.254 | 4.72 | 1.52 | 7.80 | 1.768 |
| 6 | 7/38/0.254 | 5.40 | 1.52 | 8.50 | 1.403 |
| 5 | 7/30/0.32 | 6.05 | 1.52 | 9.10 | 1.113 |
| 4 | 19/37/0.20 | 7.00 | 1.52 | 10.10 | 0.882 |
| 2 | 19/35/0.254 | 8.65 | 1.52 | 11.70 | 0.550 |
