UL Style No. 3173 lead hook up wire

Application

Internal wiring or electronic equipments, widly used in Air conditioners, microwave ovens, electronic sterilizers, electric rice burgers, electronic hot water bottles, electric.

Marking: E529032 9M AWM 3173 18AWG 105 600V XLPE wire FT2

Parameters

AWG	Conductor OD	Insulation thickness	wire O.D.	Conductor resistance
	mm	mm	mm	ohm/KM
26	0.48	0.78	2.04	138
24	0.61	0.78	2.17	85.9
22	0.77	0.78	2.33	54.3
20	0.92	0.78	2.48	33.9
18	1.19	0.78	2.75	21.4
16	1.49	0.78	3.05	13.5
14	1.89	0.78	3.45	8.45
12	2.37	0.78	3.93	5.31
10	3.02	0.78	4.58	3.343
9	3.39	0.78	4.95	2.652
