IEC60502, GB/T12706 or other standard required by customer.
The requirements for flame retardant property is according to IEC60332-3 and GB18380.
Packing:Steel/wooden reel,wooden reel or steel reel.
Installation Temperature : The installation temperature should be over 0℃ . If the ambient temperature is lower than 0℃,the cable should be preheated.
Operating Temperature : Max permissible continuous operating temperature of conductor shall not exceed 90℃ .
Conductor Short-circuit Temperature : Max temperature at short-circuit shall not exceed 250℃ . The short-circuit duration shall not exceed 5 seconds.
This product is suitable for transmission and distribution system at the voltage from LV to MV. The power cables can be flame retardant when used as type ZR.
| Description |
| Cu or Al conductor/ XLPE insulated/ steel tape armored/ PVC sheathed flame retardant power cable |
| Cu or Al conductor/ XLPE insulated/ steel tape armored/ PVC sheathed power cable |
| Cu or Al conductor/ XLPE insulated/ steel wire armored/ PVC sheathed power cable |
| Cu or Al conductor/ XLPE insulated/ steel wire armored/ PVC sheathed flame retardant power cable |
Technical Characteristics for 0.6/1kV, CU or AL conductor/ XLPE Insulated/ Steel Wire Armored/PVC Sheathed Power Cable, 3-Core
| Nominalconductorcrosssectionarea(mm) | Nominal Insulation thickness (mm) | Nominalsheaththickness (mm) | ApproxOverallDiameter (mm) | Max DCConductorresistance at20℃ (Ω/km) | Approx weight of cable(kg/km) | ||
| Cu | Al | Cu | Al | ||||
| 3x10 | 0.7 | 2.0 | 21 | 1.83 | 3.08 | 820 | 630 |
| 3x16 | 0.7 | 2.0 | 25 | 1.15 | 1.91 | 1450 | 1150 |
| 3x25 | 0.9 | 2.0 | 28 | 0.727 | 1.20 | 1850 | 1400 |
| 3x35 | 0.9 | 2.0 | 31 | 0.524 | 0.868 | 2300 | 1650 |
| 3x50 | 1.0 | 2.0 | 32 | 0.387 | 0.641 | 2650 | 1750 |
| 3x70 | 1.1 | 2.5 | 38 | 0.268 | 0.443 | 3650 | 2350 |
| 3x95 | 1.1 | 2.5 | 41 | 0.193 | 0.320 | 4550 | 2800 |
| 3x120 | 1.2 | 3.0 | 43 | 0.153 | 0.253 | 5450 | 3200 |
| 3x150 | 1.4 | 3.0 | 48 | 0.124 | 0.206 | 7000 | 4200 |
| 3x185 | 1.6 | 3.0 | 58 | 0.0991 | 0.164 | 9328 | 5849 |
| 3x240 | 1.7 | 3.5 | 65 | 0.0754 | 0.125 | 11236 | 6587 |
any interested item to armor cable, welcome to contact us freely, thank you.
